Nodweddion Spindle B7000-CT-P4S-UL 10x26x8mm Nodweddion:
Mae dwyn gwerthyd B7000-CT-P4S-UL yn addas ar gyfer llwythi rheiddiol ac echelinol uchel i un cyfeiriad
Mae gan Spindle Bearing B7000-CT-P4S-UL hefyd allu cario llwyth echelinol ar y ddwy ochr yn y trefniant X- neu O mewn cyfresi canolig parau ar gyfer ystod eang o gymwysiadau
Gradd cywirdeb Bind000 Bearing B7000-CT-P4S-UL: P4S (prif ddimensiynau o leiaf yn ôl dosbarth 4 goddefgarwch ISO)
Gan gadw gwerthyd B7000-CT-P4S-ULmaterial: 100Cr6 (dur dwyn rholio), resin ffenol (cawell)
sêl: dyluniad agored (heb sêl)
Spindle Bearing B7000-CT-P4S-ULcomparable gyda 7000CTA / P4S (CSC), 7000C (NSK), 7000 CD / P4A (SKF)
Llun Spindle B7000-CT-P4S-UL 10x26x8mm:
Data technegol 10726x8mm Gan gadw gwerthyd B7000-CT-P4S-UL:
Diamedr y Tu Mewn (mm): 10
Diamedr y Tu Allan (mm): 26
Lled (mm): 8
Cysylltwch ag Angle: 15 °
Rhesi Peli: rhes sengl
Sêl: agored
Deunydd Modrwy: Dur Chrome
Deunydd Elfen dreigl: Dur Chrome
Deunydd Cage: Resin Ffolig
Pwysau cynnyrch: 0,020 Kg
Sioe Cynhyrchion:
Modelau Cyfeirio:
| Model: | D. | B. | C. | r (min) | r1 (mun) | ra (mwyafswm) | ongl gyswllt | Pwysau (KG) |
| B7000-CT-P4S-UL | 26 | 8 | 6.4 | 0.3 | 0.3 | 0.3 | 15 ° | 0.02 |
| B7001-CT-P4S-UL | 28 | 8 | 6.7 | 0.3 | 0.3 | 0.3 | 15 ° | 0.021 |
| B7002-CT-P4S-UL | 32 | 9 | 7.6 | 0.3 | 0.2 | 0.3 | 15 ° | 0.028 |
| B7003-CT-P4S-UL | 35 | 10 | 8.5 | 0.4 | 0.3 | 0.3 | 15 ° | 0.039 |
| B7004-CT-P4S-UL | 42 | 12 | 10.2 | 0.6 | 0.3 | 0.6 | 15 ° | 0.067 |
| B7005-CT-P4S-UL | 47 | 12 | 10.8 | 0.6 | 0.3 | 0.6 | 15 ° | 0.075 |
| B7006-CT-P4S-UL | 55 | 13 | 12.3 | 1 | 0.6 | 1 | 15 ° | 0.108 |
| B7007-CT-P4S-UL | 62 | 14 | 13.5 | 1 | 0.6 | 1 | 15 ° | 0.153 |
| B7008-CT-P4S-UL | 68 | 15 | 14.7 | 1 | 0.6 | 1 | 15 ° | 0.188 |
| B7009-CT-P4S-UL | 75 | 16 | 16 | 1 | 0.6 | 1 | 15 ° | 0.239 |
| B7010-CT-P4S-UL | 80 | 16 | 16.7 | 1 | 0.6 | 1 | 15 ° | 0.254 |
| B7011-CT-P4S-UL | 90 | 18 | 18.7 | 1.1 | 0.6 | 1 | 15 ° | 0.377 |
| B7012-CT-P4S-UL | 95 | 18 | 19.4 | 1.1 | 0.6 | 1 | 15 ° | 0.401 |
| B7013-CT-P4S-UL | 100 | 18 | 20.1 | 1.1 | 0.6 | 1 | 15 ° | 0.426 |
| B7014-CT-P4S-UL | 110 | 20 | 22.1 | 1.1 | 0.6 | 1 | 15 ° | 0.577 |
| B7015-CT-P4S-UL | 115 | 20 | 22.9 | 1.1 | 0.6 | 1 | 15 ° | 0.608 |
| B7016-CT-P4S-UL | 125 | 22 | 24.7 | 1.1 | 0.6 | 1 | 15 ° | 0.836 |
| B7017-CT-P4S-UL | 130 | 22 | 25.4 | 1.1 | 0.6 | 1 | 15 ° | 0.878 |
| B7018-CT-P4S-UL | 140 | 24 | 27.4 | 1.5 | 0.6 | 1.5 | 15 ° | 1.13 |
Sylw:
Spindle Bearing B7000-CT-P4S-UL; B7001-CT-P4S-UL; B7002-CT-P4S-UL cyflenwadau; asiantaeth;
